14. Outside Universal Stiffened Anchor Bolt Charts
PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins 95
3 Stiffener per Sidewall Sheet Anchor Bolt Placement Charts (Continued)
NOTE: The tables on this page are for 3 post outside stiffened tanks only.
Nominal 72 Anchors
Diameter = 72' 3 Post
Bolt Radius = 36' - 2-1/2"
Anchor Chord
3' - 1-15/16"
6' - 3-3/4"
9' - 5-7/16"
12' - 6-15/16"
15' - 8-1/8"
18' - 8-15/16"
21' - 9-3/8"
24' - 9-1/4"
27' - 8-9/16"
30' - 7-5/16"
33' - 5-5/16"
36' - 2-9/16"
38' - 10-15/16"
41' - 6-1/2"
44' - 1-1/16"
46' - 6-5/8"
48' - 11-1/8"
51' - 2-1/2"
Nominal 75 Anchors
Diameter = 75' 3 Post
Bolt Radius = 37' - 8-7/16"
Anchor Chord
3' - 1-15/16"
6' - 3-3/4"
9' - 5-7/16"
12' - 6-15/16"
15' - 8-1/8"
18' - 9-1/16"
21' - 9-9/16"
24' - 9-5/8"
27' - 9-1/8"
30' - 8-1/16"
33' - 6-3/8"
36' - 3-15/16"
39'-3/4"
41' - 8-3/4"
44' - 3-7/8"
46' - 10-1/16"
49' - 3-1/4"
51' - 7-7/16"
Nominal 78 Anchors
Diameter = 78' 3 Post
Bolt Radius = 39' - 2-5/16"
Anchor Chord
3' - 1-15/16"
6' - 3-3/4"
9' - 5-7/16"
12' - 6-15/16"
15' - 8-3/16"
18' - 9-1/8"
21' - 9-3/4"
24' - 9-7/8
27' - 9-9/16"
30' - 8-3/4"
33' - 7-1/4"
36' - 5-3/16"
39' - 2-3/8"
41' - 10-3/4"
44' - 6-3/8"
47' - 1-1/8"
49' - 6-15/16"
51' - 11-13/16"
54' - 3-5/8"
Nominal 90 Anchors
Diameter = 90' 3 Post
Bolt Radius = 45' - 1-15/16"
Anchor Chord
3' - 1-7/8"
6' - 3-5/8"
9' - 5-5/16"
12' - 6-7/8"
15' - 8-1/4"
18' - 9-3/8"
21' - 10-1/4"
24' - 10-13/16"
27' - 10-15/16"
30' - 10-3/4"
33' - 10-1/16"
36' - 8-7/8"
39' - 7-3/16"
42' - 4-7/8"
45'-2"
47' - 10-3/8"
50' - 6-1/8"
53' - 1-1/8"
55' - 7-5/16"
58' - 0-3/4"
60' - 5-5/16"
62' - 8-15/16"
