11. Frost Free Pad Commercial Tank
52 PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
Frost Free Pad Commercial Tank (Continued)
(Refer to Figure 11A on Page 50.)
Diameter of Bin: 33'
Corrugation: 2.66''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 2 in. 2 17 ft. 0 in. 1600 1100 300 22
10 1 ft. 8 in. 2 17 ft. 3 in. 1600 1100 300 24
12 2 ft. 3 in. 3 17 ft. 6 in. 1600 1100 500 27
14 2 ft. 10 in. 3 17 ft. 6 in. 1600 1100 600 29
16 3 ft. 7 in. 4 17 ft. 10 in. 1600 1100 800 32
Diameter of Bin: 36'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 2 in. 2 18 ft. 6 in. 1900 1300 300 25
10 1 ft. 8 in. 2 18 ft. 9 in. 1900 1300 300 28
12 2 ft. 3 in. 3 19 ft. 0 in. 1900 1300 600 31
14 3 ft. 2 in. 3 19 ft. 1 in. 1900 1300 700 35
16 3 ft. 11 in. 4 19 ft. 5 in. 1900 1300 900 38
18 4 ft. 10 in. 5 19 ft. 9 in. 1900 1300 1100 43
Diameter of Bin: 39'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 3 in. 2 20 ft. 0 in. 2300 1500 300 29
10 1 ft. 9 in. 2 20 ft. 3 in. 2300 1500 300 32
12 2 ft. 4 in. 3 20 ft. 6 in. 2300 1500 600 35
14 3 ft. 2 in. 3 20 ft. 10 in. 2300 1500 700 40
16 3 ft. 11 in. 4 21 ft. 2 in. 2300 1500 1000 44
18 4 ft. 10 in. 5 21 ft. 6 in. 2300 1500 1200 49
Diameter of Bin: 42'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 4 in. 2 21 ft. 7 in. 2600 1800 300 34
10 1 ft. 10 in. 2 21 ft. 10 in. 2600 1800 300 37
12 2 ft. 5 in. 3 22 ft. 1 in. 2600 1800 700 41
14 3 ft. 2 in. 4 22 ft. 2 in. 2600 1800 900 44
16 3 ft. 11 in. 4 22 ft. 6 in. 2600 1800 1000 49
18 4 ft. 10 in. 5 22 ft. 11 in. 2600 1800 1300 54
