12. Inverted “T” Foundation 2.66" Outside Stiffened Commercial Tanks
PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
67
Diameter of Bin: 24'
Soil Bearing Capacity: 3500 PSF
Ring #
12
14
16
18
20
22
24
A
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
B
1'-9"
2'-1"
2'-6"
3'-0"
3'-6"
4'-1"
4'-8"
C
12'-10"
12'-10"
12'-10"
12'-10"
12'-10"
12'-10"
12'-10"
D
13'-0"
13'-2"
13'-4"
13'-7"
13'-10"
14'-1"
14'-4"
M
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
N
2 #5's
2 #5's
3 #5's
3 #5's
4 #5's
4 #5's
5 #5's
P
#5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c
Rerod
#4 (ft.)
2300
2300
2300
2300
2300
2300
2300
#5 (ft.)
300
400
500
500
600
700
700
#6 (ft.)
0
0
0
0
0
0
0
Cu. Yds.
Concrete
Footing
5
6
8
9
10
12
14
Wall
14
14
14
14
14
14
14
Floor
8
8
8
8
8
8
8
Total
27
28
30
31
32
34
36
Diameter of Bin: 27'
Soil Bearing Capacity: 3500 PSF
Ring #
12
14
16
18
20
22
24
A
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
B
1'-9"
2'-2"
2'-8"
3'-2"
3'-9"
4'-4"
4'-10"
C
14'-4"
14'-4"
14'-4"
14'-4"
14'-4"
14'-4"
14'-4"
D
14'-7"
14'-9"
15'-0"
15'-2"
15'-5"
15'-8"
15'-11"
M
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
N
2 #5's
3 #5's
3 #5's
3 #5's
4 #5's
5 #5's
5 #5's
P
#5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c
Rerod
#4 (ft.)
2800
2800
2800
2800
2800
2800
2800
#5 (ft.)
300
500
500
500
700
800
900
#6 (ft.)
0
0
0
0
0
0
0
Cu. Yds.
Concrete
Footing
6
7
9
11
12
14
16
Wall
15
15
15
15
15
15
15
Floor
10
10
10
10
10
10
10
Total
31
32
34
36
37
39
41
