8. Frost Free Pad Unstiffened 4.00" Farm Bin
38 PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
Frost Free Pads Unstiffened 4.00" Farm Bin
(Refer to Figure 8A on Page 37.)
Diameter of Bin: 18'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 0 in. 2 9 ft. 6 in. 600 400 200 8
8 1 ft. 7 in. 2 9 ft. 9 in. 600 400 200 9
Diameter of Bin: 21'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 1 in. 2 10 ft. 11 in. 800 500 200 10
8 1 ft. 8 in. 2 11 ft. 3 in. 800 500 200 12
Diameter of Bin: 24'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 1 in. 2 12 ft. 5 in. 1000 600 200 12
8 1 ft. 9 in. 2 12 ft. 9 in. 1000 600 200 15
9 2 ft. 6 in. 3 13 ft. 2 in. 1000 600 400 18
Diameter of Bin: 27'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 2 in. 2 14 ft. 0 in. 1200 700 200 16
8 1 ft. 10 in. 2 14 ft. 4 in. 1200 700 200 18
9 2 ft. 7 in. 3 14 ft. 7 in. 1200 700 500 21
Diameter of Bin: 30'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 2 in. 2 15 ft. 6 in. 1400 900 200 19
8 1 ft. 10 in. 2 15 ft. 10 in. 1400 900 200 21
9 2 ft. 8 in. 3 16 ft. 1 in. 1400 900 500 25
