5. Frost Free Pad FCDL
PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins 27
Frost Free Pad (FCDL Bins) (Continued)
(Refer to Figure 5A on Page 24.)
Diameter of Bin: 27'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 2 in. 2 14 ft. 3 in. 1100 800 200 16
7, 8 1 ft. 10 in. 2 14 ft. 4 in. 1100 800 200 18
9, 10 2 ft. 7 in. 3 14 ft. 7 in. 1100 800 500 21
Diameter of Bin: 30'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 2 in. 2 15 ft. 9 in. 1400 900 200 19
7, 8 1 ft. 10 in. 2 15 ft. 10 in. 1400 900 200 21
9, 10 2 ft. 8 in. 3 16 ft. 1 in. 1400 900 500 25
11, 12 3 ft. 8 in. 4 16 ft. 5 in. 1400 900 700 29
Diameter of Bin: 33'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 3 in. 2 17 ft. 3 in. 1700 1100 300 23
7, 8 1 ft. 11 in. 2 17 ft. 4 in. 1700 1100 300 25
9, 10 2 ft. 9 in. 3 17 ft. 6 in. 1700 1100 600 29
11, 12 3 ft. 10 in. 4 18 ft. 0 in. 1700 1100 800 34
Diameter of Bin: 36'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 3 in. 2 18 ft. 9 in. 2000 1300 300 26
7, 8 2 ft. 0 in. 2 18 ft. 11 in. 2000 1300 400 30
9, 10 2 ft. 10 in. 3 19 ft. 0 in. 2000 1300 600 33
11, 12 3 ft. 11 in. 4 19 ft. 6 in. 2000 1300 900 39
13 4 ft. 10 in. 5 19 ft. 9 in. 2000 1300 1100 43
Diameter of Bin: 42'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 4 in. 2 21 ft. 8 in. 2600 1800 300 34
7, 8 2 ft. 1 in. 3 21 ft. 11 in. 2600 1800 700 39
9 3 ft. 1 in. 4 22 ft. 2 in. 2600 1800 900 44
10, 11 4 ft. 2 in. 5 22 ft. 7 in. 2600 1800 1200 50
12, 13 4 ft. 10 in. 5 22 ft. 11 in. 2600 1800 1300 54
14 5 ft. 6 in. 6 23 ft. 2 in. 2600 1800 1500 66
