11. Frost Free Pad Commercial Tank
PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins 53
Frost Free Pad Commercial Tank (Continued)
(Refer to Figure 11A on Page 50.)
Diameter of Bin: 45'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 4 in. 2 23 ft. 0 in. 3000 2000 300 38
10 1 ft. 10 in. 2 23 ft. 3 in. 3000 2000 300 41
12 2 ft. 6 in. 3 23 ft. 6 in. 3000 2000 800 46
14 3 ft. 3 in. 4 23 ft. 7 in. 3000 2000 1000 49
16 4 ft. 1 in. 4 23 ft. 11 in. 3000 2000 1100 55
18 5 ft. 0 in. 5 24 ft. 4 in. 3000 2000 1400 60
Diameter of Bin: 48'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 4 in. 2 24 ft. 6 in. 3400 2300 400 43
10 1 ft. 11 in. 2 24 ft. 9 in. 3400 2300 400 47
12 2 ft. 7 in. 3 25 ft. 1 in. 3400 2300 800 51
14 3 ft. 4 in. 4 25 ft. 2 in. 3400 2300 1100 56
16 4 ft. 2 in. 4 25 ft. 6 in. 3400 2300 1200 61
18 5 ft. 1 in. 5 25 ft. 11 in. 3400 2300 1500 67
Diameter of Bin: 54'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 5 in. 2 27 ft. 6 in. 4300 2900 400 53
10 2 ft. 1 in. 2 27 ft. 9 in. 4300 2900 700 58
12 2 ft. 9 in. 3 28 ft. 1 in. 4300 2900 900 63
14 3 ft. 6 in. 4 28 ft. 2 in. 4300 2900 1200 68
16 4 ft. 5 in. 4 28 ft. 7 in. 4300 2900 1400 75
18 5 ft. 4 in. 5 29 ft. 0 in. 4300 2900 1700 82
Diameter of Bin: 60'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 6 in. 2 30 ft. 7 in. 5400 3600 400 65
10 2 ft. 2 in. 3 30 ft. 11 in. 5400 3600 900 71
12 2 ft. 10 in. 3 31 ft. 3 in. 5400 3600 1100 77
14 3 ft. 8 in. 4 31 ft. 3 in. 5400 3600 1400 82
16 4 ft. 7 in. 5 31 ft. 9 in. 5400 3600 1700 91
18 5 ft. 7 in. 6 32 ft. 2 in. 5400 3600 2100 99
