12. Inverted “T” Foundation 2.66" Outside Stiffened Commercial Tanks
PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
59
Diameter of Bin: 30'
Soil Bearing Capacity: 3000 PSF
Ring #
12
14
16
18
20
22
24
A
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
B
2'-2"
2'-8"
3'-4"
3'-11"
4'-8"
5'-3"
6'-0"
C
15'-10"
15'-10"
15'-10"
15'-10"
15'-10"
15'-10"
15'-10"
D
16'-3"
16'-5"
16'-9"
17'-0"
17'-4"
17'-7"
17'-11"
M
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
N
3 #5's
3 #5's
4 #5's
4 #5's
5 #5's
5 #5's
6 #5's
P
#5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #6 @ 14" c/c
Rerod
#4 (ft.)
3000
3000
3000
3000
3000
3000
3000
#5 (ft.)
500
500
700
700
900
900
600
#6 (ft.)
0
0
0
0
0
0
500
Cu. Yds.
Concrete
Footing
8
10
12
14
17
19
21
Wall
17
17
17
17
17
17
17
Floor
13
13
13
13
13
13
13
Total
38
40
42
44
47
49
51
Diameter of Bin: 33'
Soil Bearing Capacity: 3000 PSF
Ring #
12
14
16
18
20
22
24
A
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
B
2'-2"
2'-10"
3'-5"
4'-2"
4'-10"
5'-5"
6'-2"
C
17'-4"
17'-4"
17'-4"
17'-4"
17'-4"
17'-4"
17'-4"
D
17'-9"
18'-1"
18'-3"
18'-7"
18'-11"
19'-2"
19'-6"
M
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
5 #4's
N
3 #5's
3 #5's
4 #5's
4 #5's
5 #5's
6 #5's
6 #5's
P
#5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 14" c/c #5 @ 13" c/c #6 @ 13" c/c
Rerod
#4 (ft.)
3400
3400
3400
3400
3400
3400
3400
#5 (ft.)
600
700
800
900
1000
1200
700
#6 (ft.)
0
0
0
0
0
0
600
Cu. Yds.
Concrete
Footing
9
11
14
16
19
21
24
Wall
19
19
19
19
19
19
19
Floor
16
16
16
16
16
16
16
Total
44
46
49
51
54
56
59
