14. Outside Universal Stiffened Anchor Bolt Charts
92 PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
2 Stiffener per Sidewall Sheet Anchor Bolt Placement Charts (Continued)
NOTE: The tables on this page are for 2 post outside stiffened tanks only.
Nominal 28 Anchors
Diameter = 42' 2 Post
Bolt Radius = 21' - 3-1/2"
Anchor Chord
4' - 9-1/4"
9' - 5-3/4"
14'-3/4"
18' - 5-11/16"
22' - 7-7/8"
26' - 6-3/4"
30' - 1-5/16"
Nominal 32 Anchors
Diameter = 48' 2 Post
Bolt Radius = 24' - 3-1/4"
Anchor Chord
4' - 9-1/8"
9' - 5-11/16"
14' - 1-1/8"
18' - 6-15/16"
22' - 10-5/8"
26' - 11-11/16"
30' - 9-9/16"
34' - 3-15/16"
Nominal 36 Anchors
Diameter = 54' 2 Post
Bolt Radius = 27'-3"
Anchor Chord
4' - 9-1/16"
9' - 5-5/8"
14' - 1-5/16"
18' - 7-3/4"
23'-1/2"
27' - 3-1/8"
31' - 3-1/4"
35'-1/2"
38' - 6-9/16"
Nominal 40 Anchors
Diameter = 60' 2 Post
Bolt Radius = 30' - 2-7/8"
Anchor Chord
4'-9"
9' - 5/16"
14' - 1-7/16"
18' - 8-5/16"
23' - 1-3/4"
27' - 5-1/2"
31' - 7-1/4"
35' - 6-5/8"
39' - 3-3/8"
42' - 9-1/4"
