10. Frost Free Pad Unstiffened 2.66" Farm Bin
48 PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
Frost Free Pads Unstiffened 2.66" Farm Bin (Continued)
(Refer to Figure 10A on Page 45.)
Diameter of Bin: 54'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 5 in. 2 27 ft. 6 in. 4300 2900 400 53
10 2 ft. 1 in. 2 27 ft. 9 in. 4300 2900 700 58
12 2 ft. 9 in. 3 28 ft. 1 in. 4300 2900 900 63
14 3 ft. 6 in. 4 28 ft. 2 in. 4300 2900 1200 68
Diameter of Bin: 60'
Corrugation: 2.66"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
8 1 ft. 6 in. 2 30 ft. 7 in. 5400 3600 400 65
10 2 ft. 2 in. 3 30 ft. 11 in. 5400 3600 900 71
12 2 ft. 10 in. 3 31 ft. 3 in. 5400 3600 1100 77
