16. WC Series Outside Universal Stiffened Anchor Bolt Charts
122 PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
WC Series Outside Stiffened Tanks 3 Stiffeners per Sidewall Sheet
4" Commercial Anchor Placement Charts (Continued)
NOTE: These tables are for 3 post WC series outside stiffened bins only.
Nominal 90 Anchors
Diameter = 90' 3 Post
Bolt Radius = 45' - 1-13/16"
Anchor Chord
3' - 1-7/8"
6' - 3-5/8"
9' - 5-5/16"
12' - 6-13/16"
15' - 8-3/16"
18' - 9-5/16"
21' - 10-3/16"
24' - 10-11/16"
27' - 10-7/8"
30' - 10-5/8"
33' - 9-15/16"
36' - 8-3/4"
39' - 7-1/16"
42' - 4-3/4"
45' - 1-13/16"
47' - 10-1/4"
50'-6"
53'-1"
55' - 7-3/16"
58' - 0-9/16"
60' - 5-1/8"
62' - 8-3/4"
Nominal 105 Anchors
Diameter = 105' 3 Post
Bolt Radius = 52' - 7-3/8"
Anchor Chord
3' - 1-13/16"
6' - 3-9/16"
9' - 5-1/4"
12' - 6-13/16"
15' - 8-1/4"
18' - 9-1/2"
21' - 10-9/16"
24' - 11-3/8"
27'-12"
31' - 0-1/4"
34' - 0-3/16"
36' - 11-3/4"
39' - 10-7/8"
42' - 9-5/8"
45' - 7-15/16"
48' - 5-11/16"
51'-3"
53' - 11-11/16"
56' - 7-13/16"
59' - 3-3/8"
61' - 10-1/4"
64' - 4-1/2"
66'-10"
69' - 2-13/16"
71' - 6-15/16"
73' - 10-1/4"
