13. T-Cap Foundation 2.66" Outside Stiffened Commercial Tanks
PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
85
Soil Bearing Capacity: 4000 PSF
Diameter
27
30
33
Rings
28
30
28
30
32
28
30
32
A
1'-0"
1'-1"
1'-1"
1'-2"
1'-3"
1'-2"
1'-3"
1'-4"
B
5'-6"
6'-0"
6'-0"
6'-6"
7'-0"
6'-6"
7'-0"
7'-6"
C
14'-4"
14'-4"
15'-10"
15'-10"
15'-10"
17'-4"
17'-4"
17'-4"
D
16'-5"
16'-8"
18'-2"
18'-5"
18'-8"
19'-11"
20'-2"
20'-5"
E
1'-3"
1'-3"
1'-3"
1'-3"
1'-3"
1'-3"
1'-3"
1'-3"
F
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
1'-0"
G
0'-8"
0'-8"
0'-8"
0'-8"
0'-8"
0'-8"
0'-8"
0'-8"
M
4 #4's
4 #4's
4 #4's
4 #4's
4 #4's
4 #4's
4 #4's
4 #4's
N
6 #5's
7 #5's
7 #5's
8 #5's
10 #5's
8 #5's
9 #5's
10 #5's
P
#5 @ 10" c/c #5 @ 10" c/c
#5 @ 10" c/c
#5 @ 9" c/c
#5 @ 9" c/c
#5 @ 9" c/c
#5 @ 9" c/c
#5 @ 9" c/c
Q
#5 @ 20" c/c #5 @ 20" c/c
#5 @ 20" c/c #5 @ 18" c/c #5 @ 18" c/c
#5 @ 18" c/c #5 @ 18" c/c #5 @ 18" c/c
R
#4 @ 12" c/c #4 @ 12" c/c
#4 @ 12" c/c #4 @ 12" c/c #4 @ 12" c/c
#4 @ 12" c/c #4 @ 12" c/c #5 @ 12" c/c
Rebar
#4 (ft.)
2100
2100
2300
2300
2400
2500
2600
900
#5 (ft.)
3900
4200
4800
5300
5700
6000
6300
8300
#6 (ft.)
0
0
0
0
0
0
0
0
Cu. Yds.
Concrete
Footing
19
22
24
29
33
32
35
39
Wall
17
17
19
19
19
21
21
20
Floor
23
23
27
27
26
32
32
31
Total
59
62
70
75
78
85
88
90
Soil Bearing Capacity: 4000 PSF
Diameter
36
42
Rings
28
30
32
28
30
32
A
1'-2"
1'-3"
1'-5"
1'-3"
1'-5"
1'-6"
B
6'-8"
7'-2"
8'-0"
7'-4"
8'-0"
9'-0"
C
18'-10"
18'-10"
18'-10"
21'-11"
21'-11"
21'-11"
D
21'-6"
21'-9"
22'-2"
24'-11"
25'-3"
25'-9"
E
1'-3"
1'-3"
1'-3"
1'-4"
1'-4"
1'-4"
F
1'-0"
1'-0"
1'-0"
1'-0"
1'-1"
1'-2"
G
0'-8"
0'-8"
0'-8"
0'-8"
0'-8"
0'-8"
M
4 #4's
4 #4's
4 #4's
5 #4's
5 #4's
5 #4's
N
8 #5's
9 #5's
10 #5's
9 #5's
10 #5's
10 #6's
P
#5 @ 9" c/c
#5 @ 9" c/c
#6 @ 10" c/c
#5 @ 9" c/c
#6 @ 10" c/c
#6 @ 9" c/c
Q
#5 @ 18" c/c
#5 @ 18" c/c
#6 @ 20" c/c
#5 @ 18" c/c
#6 @ 20" c/c
#6 @ 18" c/c
R
#4 @ 12" c/c
#4 @ 12" c/c
#5 @ 12" c/c
#4 @ 12" c/c
#4 @ 12" c/c
#5 @ 12" c/c
Rebar
#4 (ft.)
2800
2800
1000
3500
3600
1500
#5 (ft.)
6700
7200
7400
8800
6900
6500
#6 (ft.)
0
0
2000
0
2400
5300
Cu. Yds. Concrete
Footing
34
39
49
47
58
68
Wall
22
22
22
28
28
28
Floor
36
37
37
48
51
54
Total
92
98
108
123
137
150
