5. Frost Free Pad FCDL
28 PNEG-318 Concrete Foundation Recommendations for GSI Grain Bins
Frost Free Pad (FCDL Bins) (Continued)
(Refer to Figure 5A on Page 24.)
Diameter of Bin: 48'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 5 in. 2 24 ft. 8 in. 3400 2300 400 44
7, 8 2 ft. 3 in. 3 24 ft. 11 in. 3400 2300 800 49
9 3 ft. 3 in. 4 25 ft. 2 in. 3400 2300 1100 55
10, 11 4 ft. 5 in. 5 25 ft. 8 in. 3400 2300 1400 63
12, 13 5 ft. 1 in. 5 25 ft. 11 in. 3400 2300 1500 67
14 5 ft. 8 in. 6 26 ft. 2 in. 5400 2300 1700 72
Diameter of Bin: 54'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 5 in. 2 27 ft. 9 in. 4800 3300 400 56
7, 8 2 ft. 3 in. 3 28 ft. 1 in. 4800 3300 600 63
9, 10 3 ft. 3 in. 4 28 ft. 4 in. 4800 3300 700 69
11, 12 4 ft. 5 in. 4 28 ft. 7 in. 4800 3300 1400 75
13, 14 6 ft. 0 in. 6 29 ft. 2 in. 4800 3300 1900 87
Diameter of Bin: 60'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 6 in. 2 30 ft. 7 in. 5400 3600 400 65
7, 8 2 ft. 10 in. 3 31 ft. 3 in. 5400 3600 1100 77
9, 10 3 ft. 8 in. 4 31 ft. 7 in. 5400 3600 1400 82
11, 12 4 ft. 7 in. 5 31 ft. 9 in. 5400 3600 1700 91
13 6 ft. 1 in. 6 32 ft. 4 in. 5400 3600 2200 103
