Kit Contents:
1253Box1:
Driver Side Knuckle
1253Box2
Pass Side Knuckle
1253Box3
Dr Fr Diff Bracket
Dr Rr Diff Bracket
Pass Diff Bracket
Front Shock Brackets (2)
1253BAG1
1253BAG6
RR Lift Blocks (2)
5/8” X 3” X 16” Square U-bolts (4)
5/8” Nut Bag For U-bolts
Front Shock Part #658741 (2)
Rr Shock Part #658704 (2)
1253Box4
Torsion Bracket Sleeves (2)
Bump Stop Brackets (2)
Fr Sway Bar Link (2)
Rr Dr Diff Brake Bracket
Rr Pas Diff Brake Bracket (2)
Rr E-Brake Bracket
Dr NTD Bracket
Pass NTD Bracket
1253BAG4
1253Box5
Rear Cross Member
Frt Cross Member
Dr Fr Brake Line
Pass Fr Brake Line
1253Box6
Front Skid Plate
Fastener Breakdown:
For Front Cross Member: 1253Bag2
18mm x 120mm Bolt (2)
18mm Nylock Nut (2)
Flat Washer (4)
For Rear Cross Member:
18mm x 140mm Bolt (2)
18mm Nylock Nut (2)
Flat Washer (4)
For Pass Side Dif Drop Brkt: 1253Bag3
12mm Lock Nut (2)
12mm x 35mm Bolt (2)
For Driver Side Front Dif Drop Brkt.
12mm x 35mm Bolt (2)
Flat Washers (2)
For Driver Side Rear Diff Drop Brkt
12mm Lock Nut
12mm x 35mm Bolt
For Front Sway Bar Links:
Sway bar Link (2)
Sway Link Washers (8)
7/16” x 3” Bolt (4)
Link Washers (8) 1253Bag7
For Front Shock Absorber Bracket
1/2” x 1 1/2” Bolt (4)
Flat Washers (8)
1/2” Lock Nut (4)
9/16” x 3 1/2” Bolt (4)
Flat Washer (8)
9/16” Lock Nut (4)
For Skid Plate:
3/8’ x 1 1/4” Bolt (4)
Flat Washer (8)
3/8” Lock Nut (4)
For Non-Torsion Bar Bracket: 1253Bag8
Sleeves (2)
3/4” X 5 1/2” Bolt (2)
3/4” Lock Nut (2)
3/4” Flat Washers (4)
For Rear Bump-stop Brackets: 1253Bag4
3/8” x 1 1/4” Bolt (4)
3/8” Flat Washer (4)
3/8” Flag Nut (2)
For Rear Brake Brackets:
5/16” Lock Nut
Flat Washer (5)
5/16” x 3/4” Bolt (4)
5/16” Lock Nut (4)
For Rear Bump-stops: 1253Bag7
Flag Nuts (4)
For Front Brake Lines: 1253Bag5
Brake Crush Washers (4)
Black Cable Ties (2)
For Rear Shocks: 1253Bag6
Shock Sleeves (4)
Rear U-bolts:
5/8” Nuts
TORQUE SPECS:
Size Grade 5 Grade 8
3/8” 30 ft/lbs 35 ft/lbs
7/16” 45 ft/lbs 60 ft/lbs
1/2” 65 ft/lbs 90 ft/lbs
9/16” 95 ft/lbs 130 ft/lbs
5/8” 135 ft/lbs 175 ft/lbs
Class 8.8 Class 10.9
10MM 32ft/lbs 45ft/lbs
12MM 55ft/lbs 75ft/lbs
18MM 170ft/lbs 240ft/lbs
10mm socket /wrench
11mm socket /wrench
13mm Deep Socket
13mm wrench
15mm socket / wrench
17mm socket / wrench
18mm socket /wrench
19mm socket /wrench
21mm socket /wrench
24mm socket /wrench
9/16 socket /wrench
Torsion bar Tool
Drill
13/32 Drill Bit
Loc-Tite
Reciprocating Saw
Floor Jack
Jack Stands
TOOLS NEEDED:
