Rough Country PERF905 - Manual (Page 9)

REAR INSTALLATION
1. Chock the front wheels. Jack up the rear of the vehicle and support the vehicle with jack stands, so that the rear
wheels are off the ground.
2. Remove the rear tires/wheels, using a 13/16” deep well socket. Place a floor jack under the differential.
3. Remove the rear track bar from the frame mount on the passenger side using a 18mm wrench and T55 torx head.
Loosen the track bar on the axle side using a T55 and 18mm wrench.
4. Using a 18mm socket and a 15mm wrench, remove the rear shocks. Retain the shock hardware for reuse.
5. Using a 15mm socket disconnect the sway bar bracket from the frame. See PHOTO 1. Using a 8mm wrench for the
sway bar link and a 15mm wrench on the nut, remove the link from the axle. See PHOTO 2. The rear sway bar will
not be used in this kit.
6. Using a 13mm wrench remove the coil spring retainer. Retain factory hardware.
7. Lower the axle and remove the stock coil spring. A coil spring or strut compressor may be needed to remove the
stock coil.
8. Using a 21mm socket and wrench remove the lower control arm. See PHOTO 3. Retain the factory hardware.
9. Remove the brake line bracket from the drive side upper control arm with a 10mm wrench, next remove the brake
line clip holding the brake line to the bracket. See PHOTO 4 & 5. Discard the factory bracket.
10. With a 10mm wrench remove the e-brake bracket from the passenger side upper control arm. See PHOTO 6.
PHOTO 1
PHOTO 2
PHOTO 4
PHOTO 2
PHOTO 3
PHOTO 5 PHOTO 6
