Rough Country PERF905 - Manual (Page 10)

11. Remove the upper control arm using a 15mm wrench and a T55 torx head.
12. Remove the lower control arm pocket with a cut off wheel. Cut down the line shown in PHOTO 8 and along the back
side of the bracket flush with the bottom of the unibody. Grind down all welds and burrs, then paint to prevent rust-
ing.
13. Using a cutting blade remove the factory muffler, this muffler can not be used with the longarm kit. A smaller after-
market muffler is required. See PHOTO 9 &10.
14. With a 11mm socket remove the 5 rear nuts of the studs holding the heat shield to the bottom side of the body. This
will provide you will more room to cut off the rear upper control arm mounts. See PHOTO 11.
15. Remove the factory brake line bracket from the driver side upper control arm pocket with a 10mm wrench. Next re-
move the brake line clip so the line can be pulled out of the bracket. Take care not to kink or bind the steel line.
The two ABS wire will also nee to be removed from this bracket. This bracket is later re-installed on the control arm.
See PHOTO 12.
PHOTO 7 PHOTO 8
PHOTO 9 PHOTO 10
PHOTO 11 PHOTO 12
