30. Using the supplied brake line bracket and 5/16” x 1.5 bolt, washer, and nut, bolt the brake to the body. Tighten with a
1/2” wrench. Next insert the brake line into the bracket and attach with the supplied brake line clip. See PHOTO 25.
31. Next unclip the ABS wire on the axle tube, pull the wire over the track bar bracket. This will allow enough slack for a
ABS wire not to pull tight when the suspension is extended. See PHOTO 26.
32. Use the 2 supplied cable ties to hold the ABS wires in place. See PHOTO 27 & 28.
33. Install the new track bar bracket into the stock frame mount on the passenger side using the 7/16” x 1 bolt, washer,
and nut. Tighten using a 5/8 socket and wrench. Insert the crush sleeve inside the track bar bracket and bolt the
bracket to the frame using a 12mm x 65 bolt, washer, and flangelock. Tighten using a 19mm socket and wrench.
See PHOTO 29.
34. Install the bar with the stock hardware in the new bracket. Tighten with a 18mm wrench and a T55 torx torque to
50ft/lbs. See PHOTO 30. Installation on the axle can be completed with the vehicle on the ground.
PHOTO 26 PHOTO 25
PHOTO 28 PHOTO 27
PHOTO 30 PHOTO 29
