16. Install 4) 7/16” x 1 bolts and washers, tighten with a 5/8 socket. See PHOTO 13.
17. Next install the factory nuts on the cross-member holding the transmission mount with a 15mm socket.
See PHOTO 14.
18. Using a body saw cut out the opening for the flagnuts by following the outside profile of the dimple in the frame.
See PHOTO 15.
19. Using the cross-member as a template drill 4- 15/32” holes (2 Each Side) on each side of the factory 10mm bolts.
See PHOTO 16.
20. Using the 94003181 flag nut for the driver side rear hole and the 94003182 flag nut for the passenger side rear hole
as shown, tighten using a 7/16” x 1.25 bolt and washer and a 5/8 socket. See PHOTO 17. Note: The tabbed nuts
can be held with pliers.
21. Using the 94003179 flag nut for the driver side middle hole and the 94003180 flag nut for the passenger side middle
hole as shown. Tighten using a 7/16” x 1.25 bolt and washer and a 5/8 socket. See PHOTO 18. Note: The tabbed
nuts can be held with pliers.
PHOTO 13 PHOTO 14
PHOTO 15 PHOTO 16
PHOTO 17 PHOTO 18
