Optional Equipment
Supplemental Specifications
924K 930K 938K
Tipping load – Tipping load – Tipping load –
full turn with full turn with full turn with
Operating 1.9 m 3 (2.5 yd 3 ) Operating 2.1 m 3 (2.75 yd 3 ) Operating 2.5 m 3 (3.25 yd 3 )
weight Fusion bucket weight Fusion bucket weight Fusion bucket
Change with options removed: kg lb kg lb kg lb kg lb kg lb kg lb
Optional counterweight 0 0 0 0 –320 –705 –502 –1,106 –320 –705 –593 –1,306
Guard, crankcase –11 –23 –16 –34 –11 –23 –13 –29 –11 –24 –17 –36
Guard, power train lower –77 –170 –77 –168 –77 –170 –69 –151 –68 –150 –67 –146
Guard, driveshaft –44 –96 –12 –26 –44 –96 –12 –26 –45 –100 –12 –27
Roading fenders –18 –38 –28 –61 –18 –38 –24 –52 –18 –38 –28 –60
Secondary steer –69 –151 –75 –164 –69 –151 –73 –161 –69 –151 –74 –162
Ride control –49 –107 –27 –59 –49 –107 –26 –57 –49 –107 –27 –59
Change with options added:
Guard, front window +34 +74 +17 +37 +34 +74 +18 +39 +34 +74 +18 +39
Guard, rear waste gate +276 +608 +596 +1,313 +276 +608 +488 +1,075 +276 +608 +581 +1,280
Guard, power train side +11 +24 +10 +22 +11 +24 +9 +19 +11 +24 +10 +22
Cold start package +54 +119 +104 +229 +54 +119 +74 +163 +54 +119 +101 +222
Optional tool box +44 +96 +37 +81 +44 +96 +25 +55 +44 +96 +36 +79
Logger counterweight +400 +881 +661 +1,456 +400 +881 +557 +1,227 +400 +881 +645 +1,421
33
