938K Operating Specifications with Buckets
Light Material
High Lift
Pin On
Fusion
Rated capacity
m
3
3.5
4.2
5.0
3.5
4.2
5.0
–
yd
3
4.6
5.5
6.5
4.6
5.5
6.5
–
Struck capacity
m
3
3.3
4.0
4.8
3.3
4.0
4.8
–
yd
3
4.3
5.2
6.3
4.3
5.2
6.3
–
Width: bucket
mm
2750
2750
2750
2750
2750
2750
–
ft/in
9'0"
9'0"
9'0"
9'0"
9'0"
9'0"
–
Nominal material density, 100% fill factor
kg/m
3
1378
1114
934
1313
1062
890
–
lb/yd
3
2311
1,875
1,583
2202
1,787
1,508
–
Clearance: full lift, 45° dump
mm
2691
2571
2571
2654
2534
2534
+581
ft/in
8'9"
8'5"
8'5"
8'8"
8'3"
8'3"
+1'10"
Reach: full lift, 45° dump
mm
1174
1294
1294
1210
1331
1331
+267
ft/in
3'10"
4'2"
4'2"
3'11"
4'4"
4'4"
+11"
Reach: 2130 mm (7'0") clearance, 45° dump
mm
1608
1654
1654
1622
1666
1666
+666
ft/in
5'3"
5'5"
5'5"
5'3"
5'5"
5'5"
+2'2"
Reach: level arm, level bucket
mm
2642
2812
2812
2694
2864
2864
+607
ft/in
8'8"
9'2"
9'2"
8'10"
9'4"
9'4"
+1'11"
Dig depth
mm
100
100
100
101
101
101
+35
in
3.9"
3.9"
3.9"
4"
4"
4"
+1.4"
Length: overall
mm
7794
7964
7964
7846
8016
8016
+740
ft/in
25'6"
26'1"
26'1"
25'8"
26'3"
26'3"
+2'5"
Height: overall
mm
5346
5507
5786
5376
5539
5820
+581
ft/in
17'6"
18'0"
18'11"
17'7"
18'2"
19'1"
+1'10"
Turning radius, bucket at carry
mm
6174
6227
6227
6190
6244
6244
+357
ft/in
20'3"
20'5"
20'5"
20'3"
20'5"
20'5"
+1'2"
Tipping load – straight, ISO 14397-1*
kg
11 332
11 018
11 001
10 847
10 549
10 526
–3003
lb
24,975
24,282
24,247
23,907
23,249
23,198
–6,618
Tipping load – straight, rigid tire**
kg
11 804
11 477
11 460
11 299
10 988
10 964
–3128
lb
26,016
25,294
25,257
24,903
24,217
24,164
–6,893
Tipping load – full turn, ISO 14397-1*
kg
9646
9359
9340
9194
8921
8895
–2625
lb
21,259
20,626
20,584
20,262
19,662
19,605
–5,785
Tipping load – full turn, rigid tire**
kg
10 262
9956
9936
9780
9491
9463
–2793
lb
22,616
21,943
21,898
21,556
20,917
20,856
–6,154
Breakout force
kg
11 750
10 331
10 281
11 263
9936
9888
–502
lb
25,897
22,768
22,659
24,822
21,899
21,792
–1,106
Operating weight
kg
15 730
15 869
15 937
16 131
16 270
16 335
+249
lb
34,668
34,975
35,124
35,551
35,859
36,002
+549
* Full compliance to ISO 14397-1 (2007) Sections 1 through 6, which requires 2% verification between calculation and testing.
** Compliance to ISO 14397-1 (2007) Sections 1 through 5.
Dimensions listed are for a 938K configured with bucket, bolt-on cutting edge, heavy counterweights, additional guarding, 80 kg (176 lb)
operator, and Michelin 20.5 R25 (L-3) XHA2 tires at a pressure of 4.48 bar (65 psi) in the front tires and 2.76 bar (40 psi) in the rear tires.
