VEGA VEGAPULS 56V - Manual (Page 28)

28 VEGAPULS 56V
Flange dimensions according to ANSI
D = outer flange diameter
b = flange thickness
k
= diameter of hole circle
d
1
= seal ledge diameter
f = seal ledge strength
1 /
16
" = approx. 1,6 mm
d
2
= diameter of holes
External indicating instrument VEGADIS 50
Adjustment module MINICOM
Mounting on carrier rail 35␣ x␣ 7,5 according to EN␣ 50␣ 022 or flat
screwed
Adjustment module for insertion into
VEGAPULS 56 sensors or into the external
indicating instrument VEGADIS 50
Size Flange Seal ledge Holes
D b k d
1
No. d
2
2" 150 psi 152,4 19,0 120,7 91,9 4 19,1
3" 150 psi 190,5 23,8 152,4 127,0 4 19,1
4" 150 psi 228,6 23,8 190,5 157,2 8 19,1
6" 150 psi 279,4 25,4 241,3 215,9 8 22,4
Technical data
,,,,,,,,,,,,,
,,,,,,,,,,,,,
,,,,,,,,,,,,,
,,,
,,,
,,,
,,
,,
,,
f
d
b
d
k
D
2
4
82
Pg 13,5
118 108 135
38
85
ø5
10
48
Note:
Cable diameter of the connection cable min. 5␣ mm
and max. 9␣ mm. Otherwise the seal effect of the
cable entry will not be ensured.
- +
ESC
OK
Tank 1
m (d)
12.345
74
32,5
67,5
