VEGAMET 515V 7
Relay outputs
Number 2 operating relays
1 fail safe relay
Contact floating spdt
Contact material AgNi, hard gold plated
Turn-on voltage min. 10 mV DC
max. 250 V AC/DC
Switching current min. 10 µA
max. 3 A AC, 1 A DC
Breaking capacitance max. 500 VA, 54 W
Min. switching hysteresis
(Low-/High-Delta)
0.5 %
DISBUS output
Function for linking signal conditioning instruments with
another and for connecting digital indicating
instruments
Connection cable 2-wire standard cable (screening is
recommended)
max. cable length 1000 m
max. resistance per wire 15
Ω
Indicating elements
Clear text indication LC display
(not available with 515VN) - 4-line, 6 digits each
- background lighting
Analogue indication LED chain consisting of:
(not available with 515VN) - 11 segments 0 % … 100 %
- shows the actual value of the measurement
loop
LEDs in front plate green: operating voltage on
red: fault signal (LED lights with deenergised
relay)
yellow: relay status (standard setting:
LED lights with energised relay)
Adjustment elements
Front plate 6 keys for configuration and parameter
adjustment (not available with 515VN)
Circuit board rotary switch for adjustment of the instrument
address on DISBUS
Ambient conditions
Permissible ambient temperature -20°C … +60°C
Storage and transport temperature -40°C … +80°C
Electrical connection
Multiple plug component acc. to DIN 41 612, series F, 33-pole, 3 rows
d, b, z (partly equipped)
Carrier BGT 596 (Ex) connection to the appropriate module
Housing type 505 or type 506 connection to screw terminals (max. 2.5 mm 2 )
Product description
