H8920-1 INSTALLATION GUIDE
NETWORK VARIABLE DETAILS
Name Type Range Description
nv1 nvoEgyWH 0-1e38kWH kWH Consumption
nv2 nvoPower_f 0-1e38kW kW Real Power
nv3 nvoVAR 0-1e38kW kVAR Reactive Power
nv4 nvoVA 0-1e38kW kVA Apparent Power
nv5 nvoPF 0-1 Power Factor
nv6 nvoLLVolts 0-1e38V Voltage, Line to Line
nv7 nvoLNVolts 0-1e38V Voltage, Line to Neutral
nv8 nvoAmps 0-1e38A Amps
nv9 nvoAPower 0-1e38kW Real Power, Phase A
nv10 nvoBPower 0-1e38kW Real Power, Phase B
nv11 nvoCPower 0-1e38kW Real Power, Phase C
nv12 nvoAPF 0-1 Power Factor, Phase A
nv13 nvoBPF 0-1 Power Factor, Phase B
nv14 nvoCPF 0-1 Power Factor, Phase C
nv15 nvoABVolts 0-1e38V Voltage, Phase A to Phase B
nv16 nvoBCVolts 0-1e38V Voltage, Phase B to Phase C
nv17 nvoACVolts 0-1e38V Voltage, Phase A to Phase C
nv18 nvoANVolts 0-1e38V Voltage, Phase A to Neutral
nv19 nvoBNVolts 0-1e38V Voltage, Phase B to Neutral
nv20 nvoCNVolts 0-1e38V Voltage, Phase C to Neutral
nv21 nvoAAmps 0-1e38A Amperage, Phase A
nv22 nvoBAamps 0-1e38A Amperage, Phase B
nv23 nvoCAmps 0-1e38A Amperage, Phase C
nv24 nvoAvePower 0-1e38kW kW Average power since last reset
nv25 nvoMinPower 0-1e38kW kW Minimum power since last reset
nv26 nvoMaxPower 0-1e38kW kW Maximum power since last reset
nv27 nviEgyClr See text Resets nvoEgykWH to zero
nv28 nviPwrClr See text Resets nvoAvePower, nvoMidPower and nvoMaxPower to zero
nv29 nviMeterIndex 1-63 Selects Modbus address
nv30 nvoMeterIndex 1-63 Reports selected Modbus address
nc49 nciMaxSendT 0.0-6553.4s Maximum time between nvoPower updates. Default is 0 (disabled)
nc52 nciMinSendT 0.0-6553.4s Minimum time between nvoPower updates. Default is 15 secs
nc88 nciMinDelta 0.0-100% Percent change in nvoPower that will force an nvoPower update. Default is 5%. Set to 0.0% to disable
nc49 nciMaxSendTg 0.0-6553.4s Maximum time between updates to all network variables. Default is 0 (disabled)
