SPECIFICATIONS

General
Operating Temp. Range .........................................0 to 60ºC (<95%RH, non-condensing)
Storage Temp. Range .............................................-40ºC to 70ºC
Power Source .........................................................120 VAC (+10/-25%), line-to-neutral, 50/60 Hz. (240VAC for H663SM-

xxE

)

Measured Current Inputs
Number of Channels ...............................................42
Frequency ..............................................................50/60 Hz.
Sample Frequency .................................................1280 Hz.
Update Rate ...........................................................1.2 sec
Accuracy .................................................................±5% from 5A to 50A

10A to 100A (H663SM-42H only)

Connection to Conductor .......................................Inductive split-core CT

Network Communications
Type ........................................................................Modbus RTU
Connection .............................................................DIP switch-selectable 2-wire or 4-wire
Address ..................................................................DIP switch-selectable address 1 to 247
Baud Rate ...............................................................DIP switch-selectable 2400, 4800, 9600, 19200
Parity .....................................................................DIP switch-selectable NONE, ODD, EVEN
Communication Format .........................................8-data-bits, 1-start-bit, 1-stop-bit
Termination ...........................................................5-position depluggable connector

Defaults
Warning Register ...................................................60% of current sensor max. (conﬁgurable)
Alarm Register .......................................................70% of current sensor max. (conﬁgurable)
Breaker Size Register ..............................................20A

Dimensions
Circuit Board(L x W) .................................................7.25” x 5.75”
Split-Core CT’s (6’ leads) ...........................................1.04" x 1.04" x 1.58"

Lithium Battery Life .................................................5 years (Replace with type CRF 1220 or equiv.)

CAUTION! DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE

ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISPOSE OF
USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

Measured Currents .............................. Current Range 0-50A or 0-100A (H663SM-42H)
Primary Fusing .................................... 250VAC/100mA, 5x20mm, (if equipped)Littlefuse 218 series or equivalent

Safety
UL Listed under standard 508 as an “open type device”.
Critical components evaluated to UL 1950

U.S. Patent Number 6,330,516
