35
All applications must be approved by DANA. Specifications and/or design are subject to change without notice or obligation.
WING SERIES 209M90-9C
Description
209M90-9C
Universal Joint 3 Lips sealing 3050231000 R 3L HWD
Universal Joint 3 Lips sealing 3050427000 SF 3L HWD
Slip Joint without U-Joint 3640770002 YS 307 130 1/2“ 20 UNF 25° 115x7,5
Slip Joint without U-Joint 3640770006 YS 307 130 1/2“ 20 UNF 25° 115x7,5
Slip Joint without U-Joint 3480000063 YS 307 130 M12 25° 115x7,5
Tube Yoke 3637290000 73 1/2“ 20 UNF 30° 115x7,5
Tube Yoke 3637290017 73 M12 30° 115x7,5
Midship shaft for
center bearing ø90
Tube (Length 1 meter) 3821150075 115x7,5
Bolt 3815300015 HWD 63,5-31,75 useful 1/2“ 20 UNF
Bolt 3815170013 HWD 65-30 useful M12
Central Bearing SKF
Type FYJ 90 TF 187x187
Short couple without U-joint 3699600023 SCY 223,4 40 1/2“ 20 UNF 25°
Short couple without U-joint 3699600022 SCY 245,4 72 1/2“ 20 UNF 25°
Short couple without U-joint 3699600025 SCY 289,4 75 1/2“ 20 UNF 25°
Short couple without U-joint 3699600024 SCY 333,4 95 1/2“ 20 UNF 25°
Short couple without U-joint 3699600027 SCY 370,4 95 1/2“ 20 UNF 25°
Short couple without U-joint 3698092000 SCY 395,4 130 1/2“ 20 UNF 25°
Kit sliding shaft without tube
(fix joint and slip joint)
Kit sliding shaft without tube
(fix joint and slip joint)
Double Joint without
U-Joints (H element)
Double Joint without
U-Joints (H element)
3640860001
3600000999 SF 3L HWD YS 150 1/2“ 20 UNF 30° 115x7,5
3600001005 R 3L HWD YS 150 1/2“ 20 UNF 30° 115x7,5
3634200000 46,8 1/2“ 20 UNF 9°
3634200008 76,2 1/2“ 20 UNF 15°
3645319000 SS 293 1/2“ 20 UNF 25° 115x7,5
SIC P/N
U-Joint
Style
Sealing
Style
Blocks Style
Shafts
Style
min.
Length
[mm]
Slip
[mm]
Ang.
Tube
Dim
mm
Holes
Thread
