DRIVESHAFT COMPONENTS Compact 2015 - 2065
*Legend: Lube= u-joint with nipple, relube SF= u-joint w/o nipple, prelube
Compact 2045/47
Description
U-Joint
Type*
Slip
mm
Length
mm
Type of
Flange
H Flange
mm
Holes
Holes
Dia mm
H C/B
mm
Tube Seat
mm
Max
Ang°
drawing part
no. SGWB
part no. SIC
Midship Assy with
C/Bearing dia 55 with Lube XS 180 80 4 15,00 69,1 200,0 120x4 7 613 55 09 00 800 3A451914C7
grease nipple
Midship Assy with
C/Bearing dia Lube 150 XS 180 100 4 15,00 69,1 200,0 120x4 7 613 55 09 00 970 3A451909C7
55x18 mm
Centre Bearing Assy dia
55x18 mm for above with Lube 30,0x15,0 69,1 200,0 6 613 55 01 00 560 3A501711A8
grease nipple (DAF)
Midship Assy with
C/Bearing elastic dia SF 136 XS 180 80 4 15,00 90 220,0 120x4 7 113 55 09 00 533
55x22 mm (Iveco)
Centre Bearing Assy
elastic dia 55x22 mm SF 15,0 round 90 220,0 6 613 55 01 00 930
from above (Iveco)
Midship Assy with
C/Bearing dia 55x18 mm SF 130 XS 180 80 4 15,00 71,5 200,0 120x4 7 613 55 09 00 710
(Iveco)
Centre Bearing Assy dia
55x18 mm from above SF 15,0 round 71,5 200,0 6 613 55 01 00 610
(Iveco)
Midship Assy with
C/Bearing 75x26 mm SF 110 267 220,0 120x4 25° 7 613 75 08 00 280 0273
MIS-Version (MAN)
Centre Bearing Assy dia
75x26 mm from above SF 220,0 6 613 75 01 00 060
(MAN)
Midship Assy with
C/Bearing 75x26 mm
MIS-Version (Iveco for
ex. Stralis, Trakker)
Central Bearing Assy dia
75x26 mm from above
(Iveco for ex. Stralis,
Trakker)
Midship Assy with
C/Bearing 75x26 mm
MIS-Version (Iveco for
ex. Eurocargo)
Centre Bearing Assy dia
75x26 mm from above SF 15,0 round 220,0 6 613 75 01 00 090
(for ex. Stralis, Trakker)
Boot from above MIS-
Version (MAN and Iveco)
Double Joint Lube 320 DIN 180 90 8 16,10 120x4 42° 9 587 35 05 00 400
Double Joint Lube 320 DIN 180 90 10 16,10 120x4 42° 9 587 35 05 00 430
Cardboard Tube 300 120x4 5 000 00 08 20 051
Cardboard Tube 300 120x5 5 000 00 08 20 042
Tube 110x5 110x5 3 000 00 01 01 425
Tube 120x4 120x4 3 000 00 01 01 031
Tube 120x5 (2047) 120x5 3 000 00 01 01 469
* also order Tube Cover
SF 110 267 15,0 round 220,0 120x4 25° 7 613 75 08 00 100 0325
1 000 00 84 01 011
SF 110 267 15,0 round 220,0 120x4 25° 7 613 75 08 00 300 0325
SF 15,0 round 220,0 6 613 75 01 00 090
15,0x21,0
x17,0
15,0x21,0
x17,0
Bracket
Holes L
mm
24
