WING SERIES 115M50-5C
Legend u-joint kit style: RE = relube, with nipple RB = nipple on caps LM = though holes with nipple hole plugged, prelube SF = prelube
Legend blocks style: HW = high wing LW = low wing DW = delta shape wing D = though hole T = threaded
Legend sealing style: 2L = two lips seal 3L = three lips seal
Legend shaft style: SS = sleeve yoke + stub shaft SC = short couple std. execution YS = yoke shaft + tube sleeve SCY = short couple inverted slip
Description SIC P/N
U-Joint
Style
Sealing
Style
Blocks Style
Shafts
Style
min.
Length
[mm]
Slip
[mm]
Ang.
Tube
Dim
mm
Holes
Thread
SERIE 115M50-5C
Universal Joint 3 Lips Sealing 3050776020 R 3L HWD
Universal Joint 3 Lips Sealing 3050370000 SF 3L HWD
Slip Joint without U-Joint 3640720003 SS 192,5 60 3/8“ 24 UNF 30° 58x4
Slip Joint without U-Joint 3640720005 YS 251 110 3/8“ 24 UNF 30° 58x4
Midship shaft for center
bearing ø45
Tube Yoke 3641040000 3/8“ 24 UNF 30° 58x4
Tube (Length 1 meter) 3820580040 58x4
Bolt 3815300007 HWD 44,45 -25,4 useful 3/8“ 24 UNF
Central Bearing SKF
Type SY 40 TF 49,2 x 135
Central Bearing SKF
Type SY 45 TF 54 x 135
Short couple without U-joint 3697481000 SS 85 20 3/8“ 24 UNF 7°
Short couple without U-joint 3697748000 SS 85 20 M10 7°
Short couple without U-joint 3635250036 SS 131 26 3/8“ 24 UNF 17°
Short couple without U-joint 3635250006 SS 153 45 3/8“ 24 UNF 17°
Short couple without U-joint 3635250050 SS 177 45 3/8“ 24 UNF 17°
Short couple without U-joint 3635250038 SS 201 45 3/8“ 24 UNF 17°
Short couple without U-joint 3697747000 SS 201 45 M10 17°
Short couple without U-joint 3635250034 SS 227 72 3/8“ 24 UNF 17°
Short couple without U-joint 3635250031 SS 270 72 3/8“ 24 UNF 30°
Slip Joint without U-Joint 3612881001 R SS 270 72
Kit sliding shaft without tube
(fix joint and slip joint)
Kit sliding shaft without tube
(fix joint and slip joint)
Double Joint without
U-Joints (H element)
Double Joint without
U-Joints (H element)
3640860012
3612881000 SS 208 3/8“ 24 UNF 30° 58x4
3720001177
3600001001 R 3L HWD SS 60 3/8“ 24 UNF 30° 58x4
3600001101 R 2L HWD SS 60 3/8“ 24 UNF 30° 58x4
3633720003 31 3/8“ 24 UNF 15°
3633720000 46 3/8“ 24 UNF 20°
30
