Spicer SERVICE CATALOG - Manual (Page 15)

DRIVESHAFT COMPONENTS Compact 2015 - 2065
*Legend: Lube= u-joint with nipple, relube SF= u-joint w/o nipple, prelube service free
Description
U-Joint
Type*
Slip
mm
Length
mm
Type of
Flange
H Flange
mm
Holes
Holes
Dia mm
H C/B
mm
Tube Seat
mm
Max
Ang°
Bracket
Holes L
mm
13
All applications must be approved by DANA. Specifications and/or design are subject to change without notice or obligation.
U-Joint 30,2x82 mm Lube 7 687 20 06 00 000 3050A12000
U-Joint 30,2x82 mm SF 7 687 20 06 00 160 3050528000
Flange Yoke DIN 100 54 6 8,25 25° 2 687 20 20 00 070 3000000694
Flange Yoke Blank DIN 120 54 25° 3 687 20 20 00 000 3000009562
Flange Yoke DIN 120 54 8 8,25 25° 2 687 20 20 00 060 3000008070
Flange Yoke DIN 120 54 8 10,25 25° 2 687 20 20 00 000 3000000681
Flange Yoke DIN 120 62 8 10,25 25° 2 687 20 20 00 050 3000031731
Flange Yoke DIN 120 62 6 10,25 25° 2 687 20 20 99 000 3000031280
Flange Yoke
centering sublime
Flange Yoke
XS 120 54 4 11,00 25° 2 687 20 20 00 500 3000004123
Flange Yoke SAE 1400 SAE 115,9 48 4 12,25 25° 2 687 20 24 00 000 3000000564
Tube Yoke 53 76,2x2,4 25° 2 687 20 40 00 000 5011686
Yoke Shaft Assembly
w/o U-Joint
Yoke Shaft Assembly
w/o U-Joint
Yoke Shaft Assembly
w/o U-Joint
Yoke Shaft Assembly
w/o U-Joint (Iveco Daily)
Yoke Shaft Assembly
with U-Joint
Yoke Shaft Assembly
with U-Joint
Fixed Joint
Lube 107 DIN 120 54 8 10,25 76,2x2,4 25° 7 687 20 04 01 000 3000000982
Fixed Joint Lube 107 XS 120 54 4 11,00 76,2x2,4 25° 7 687 20 04 01 050 3000004128
Fixed Joint SAE 1400 Lube 101 SAE 115,9 48 4 12,25 76,2x2,4 25° 7 687 20 04 01 001 3000000965
Extra Short Coupling
Male and Female w/o
U-Joints and Cover Tube *
Slip Joint for Short
Coupling w/o U-Joints
and Cover Tube,
internal tube seat *
Cover Tube 100 125 6 687 20 09 00 000 0125 3000540609
Tube 76,2x2,4 3 000 00 01 01 263 3000000673
* also order Tube Cover
© Dana Spicer
Compact 2020
DIN 120 54 6 10,25 25° 2 687 20 24 00 060 3000032431
SF 70 193 76,2x2,4 25° 6 687 20 70 80 200 0183 3000000807
SF 100 233 76,2x2,4 25° 6 687 20 70 80 210 0213 3000001399
SF 140 273 76,2x2,4 25° 6 687 20 70 80 220 0253 3000009469
SF 90 230 76,2x2,4 20° 6 687 20 71 80 099 0240 3000034111
Lube 70 247 DIN 120 54 8 10,25 76,2x2,4 25° 7 687 20 07 01 200 0183 3000000981
Lube 100 277 DIN 120 54 8 10,25 76,2x2,4 25° 7 687 20 07 01 210 0213 3000009561
SF 70-27 209-166 25° 6 687 20 70 30 600 0168 3000540656
SF 100-33 220-153 76,2x2,4 25° 6 687 20 70 80 000 0213 3000540147
