Data Sheet
Standard Variant 0.08
Driveshaft
with length compensation and centered double joint on one side
100
50
0
0
10
20
30
40
To
rq
ue
%
Deflection angle
β
[ °]
Recommended connection
Companion flanges
- DIN:
according to ISO 7646
- SAE:
according to ISO 7647
- XS :
Cross serration according to ISO 8667
Driveshaft flange yokes
- XS : Cross serration according to ISO 12667
Please note:
All values given are nominal. Exact information
should only be obtained from drawing.
Attention:
Not all DIN/SAE-flange-connection can transmit
the function-limit-torque of the corresponding
driveshaft size by friction.
Design
All applications must be approved by Dana. Specifications and/or design are subject to change without notice or obligation.
β
1
S
D
K
M
1
Z
M
2
L
z
A
β
Transmission capacity dependent on deflection
angle for a centred double joint
Compact
687.30 687.35 687.45
Funktional limit torque
T
cs
kNm
3,9 6,5 7,4 8,3
17,0
Connection
-
DIN 120
DIN 150
DIN 150
KV 150
DIN 180
Flange-ø
A mm
120
150
150
150
180
Max. Joint angle
ß
°
42
42
42
Max. Joint angle
ß
1
°
25
35 25
25
Max. Rotation-ø
K mm
140
150
180
Standout M
1
mm
72
78
95
75
90
Standout M
2
mm
72
70
75
78
95
Compressed length
L
z min.
mm
600
604
766
749
725
Sliding movement
L
a
mm
110
190
110
Standout
Z mm
102
115
140
Tube
D x S
mm
90 x 3
85 x 5
120 x 4
Weight of 1m-shaft
G
W
kg
24,4 kg
25,7 kg
35,0
36,0
55,2
Weight of 1m-tube
G
R
kg
6,4
9,9
11,4
