DRIVESHAFT COMPONENTS Compact 2015 - 2065
*Legend: Lube= u-joint with nipple, relube SF= u-joint w/o nipple, prelube
Description
U-Joint
Type*
Slip
mm
Length
mm
Type of
Flange
H Flange
mm
Holes
Holes
Dia mm
H C/B
mm
Tube Seat
mm
Max
Ang°
drawing part
no. SGWB
part no. SIC
U-Joint 59x167,7 mm Lube 7 687 60 06 00 000 3A605801A6
U-Joint 59x167,7 mm SF 7 687 60 06 00 160 3A605801C6
Flange Yoke XS 180 100 4 15,00 30° 2 687 60 23 00 510 3A602002C2
Flange Yoke SAE 1800
4x3 holes, pilot diameter SAE 203,2 86 12 11,10 25° 2 687 60 24 00 010 3A602005B2
male 196,8 mm
Tube Yoke 105 130x6 30° 2 687 60 40 00 000 3A602102A2
Yoke Shaft Assembly
w/o U-Joint
Sleeve Muff 110 184 130x6 2 687 60 80 00 000 0184
Cover Tube 110 132 6 687 60 09 00 000 0132 3A603402G6
Yoke Shaft Assembly
with U-Joint
Fixed Joint Lube 205 XS 180 100 4 15,00 130x6 30° 7 687 60 04 01 050 3A602901C7
Yoke Shaft Assembly
for Short Coupling w/o 110-50 285-225 130x6 25° 6 687 60 70 80 099 0268 3720000790
U-Joint and Cover Tube *
Midship Assy with
C/Bearing dia 70x26 mm
Centre Bearing Assy dia
70x26 mm from above
Midship Assy with
C/Bearing Dia 70x20 mm 185 XS 180 107 4 15,00 85,8 220,0 130x6 7 613 70 09 00 570 3A601901C7
full rubber (DAF)
Centre Bearing Assy
dia 70x20 mm from
above full rubber shore
80 (DAF)
Midship Assy with
C/Bearing dia 70x20 mm
Centre Bearing Assy dia
70x20 mm from above
Midship Assy with
C/Bearing dia 70x20 mm
Centre Bearing Assy
dia 70x20 mm from
30,0x15,0 85,80 220,0 6 613 70 01 00 050 3A551703A8
above shore 65
Midship Assy with
C/Bearing Dia 185 XS 180 90 4 15,00 79,40 203,0 130x6 7 613 70 09 00 860
70x48,5 mm
Cardboard Tube 300 130x6 5 000 00 08 20 044
Tube 130x6 1 000 00 01 01 316
* also order Tube Cover
110 285 130x6 30° 6 687 60 70 80 200 0310 3A603710A6
Lube 110 385 XS 180 100 4 15,00 130x6 30° 7 687 60 07 01 250 0310 3A603901C7
SF 162 XS 180 107 4 15,00 90,00 220,0 130x6 7 113 70 09 00 514
SF 15,0 round 90,00 220,0 6 613 70 01 00 360
30,0x15,0 85,8 220,0 6 113 70 01 84 060 3S551701A8
185 XS 180 107 4 15,00 85,8 220,0 130x6 7 613 70 09 00 500 3A601902C7
15,0 round 85,8 220,0 6 613 70 01 00 030 3A701701A8
185 XS 180 107 4 15,00 85,8 200,0 130x6 7 613 70 09 00 600 3A601903C7
Compact 2060
Bracket
Holes L
mm
27
