WING SERIES 206M80-8C
Legend u-joint kit style:
RE = relube, with nipple
RB = nipple on caps
LM = though holes with nipple hole plugged, prelube
SF = prelube
Legend blocks style:
HW = high wing
LW = low wing
DW = delta shape wing
D = though hole
T = threaded
Legend sealing style:
2L = two lips seal
3L = three lips seal
Legend shaft style: SS = sleeve yoke + stub shaft
SC = short couple std. execution
YS = yoke shaft + tube sleeve
SCY = short couple inverted slip
Description
206M80-8C
Universal Joint 2 Lips sealing
3050A62000
R
3L
HWD
Universal Joint 2 Lips sealing
3050423000
SF
2L
HWD
Universal Joint 3 Lips sealing
3050A64000
SF
3L
HWD
Slip Joint without U-Joint
3640750002
SS
256,5
76
1/2“ 20 UNF
30°
93x5
Tube Yoke
3635050000
65
1/2“ 20 UNF
30°
93x5
Slip Joint without U-Joint
3480000040
YS
301
130
1/2“ 20 UNF
30°
100x6
Tube Yoke
3635050007
65
1/2“ 20 UNF
30°
100x6
Tube (Length 1 meter)
3820950075
95x7,5
Tube (Length 1 meter)
3065580102
100x6
Bolt
3815300014
HWD 50,8-31,75 useful
1/2“ 20 UNF
Central Bearing SKF
Type SY 65 TF 203x76,2
Kit sliding shaft without
tube (fix joint and slip joint)
Kit sliding shaft without
tube (fix joint and slip joint)
Short couple without U-joint
3699530007
R
SC
222,5
50
1/2“ 20 UNF
30°
Short couple without U-joint
3699530012
R
SC
261,6
60
1/2“ 20 UNF
30°
Short couple without U-joint
3697765000
SC
364,4
60
1/2“ 20 UNF
30°
3640860013
3600001108
R
3L
HWD
YS 130
1/2“ 20 UNF
30°
100x6
3600001109
SF
3L
HWD
YS 130
1/2“ 20 UNF
30°
100x6
SIC P/N
U-Joint
Style
Sealing
Style
Blocks Style
Shafts
Style
min.
Length
[mm]
Slip
[mm]
Ang.
Tube
Dim
mm
Holes
Thread
33
