Page 42

EN-36
CD-11 Indicator
Capacity (lb or kg)*
5 to 20,000
...........
Graduation (readability) lb or kg*
0.001 to 20
Maximum Displayed Resolution
1: 20,000
LFT Resolution
1:5000
Weighing Units*
lb, kg, oz, g**
Functions*
Parts counting, Display hold
Over Range Capacity
Maximum Capacity +9d
Stabilization Time
< 3 seconds
Auto-Zero Tracking*
Off, 0.5, 1, or 3 divisions
Zeroing Range*
2%, 18%, or 100% of capacity
Span Calibration*
5kg/lb to 100% of scale base capacity
Weighing System
Analog strain gauge load cell
Load Cell Excitation Voltage
5V dc
Load Cell Input Sensitivity
Up to 3mV/V
Load Cell Drive
4 x 350 ohm load cells
Display
1 in./2.5 cm digit height
...........
1.5 in./3.8 cm high x 4.9 in./12.5 cm wide backlit LCD
Power
AC 120 or 230 V ac and 240 Vac, 43-63 Hz or 6 alkaline C-type batteries
Typical Battery Life
up to100 hours with one 350 ohm load cell
Operating Temperature
-10°C to 40°C (14°F to 104°F)
Keyboard
4 function membrane switches
Dimensions (WxDxH) (in/cm)
8.25 x 6.75 x 3/20.0 x 17.2 x 7.7
Shipping Packing Dimensions (in/cm)
13 x 9 x 5/32 x 22.5 x 12.5
Net Weight (lb/kg)
1.3/0.6
Shipping Weight (lb/kg)
3/1.5
5.6 Technical Data (Cont.)
* User selectable
** g unit not available for full scale capacities 100kg and above.
Legal for Trade/Type approvals: NTEP, Canada Weights and Measures, CE/OIML
