EN-26

CD-11 Indicator

4. OPERATION

Before using the Indicator, make sure it has been properly set up and calibrated. Refer to Sections 2 and 3 and
the Overview of Controls and Indicator Functions to review settings.

4.4 Tare Operation

When weighing material or objects that must be held in a container, taring
stores the container weight in the Indicator’s memory. To store the container
weight, proceed as follows:

4.1 Turning On Indicator

Press the ON ZERO/

Off button until the LCD display

appears. The display momentarily displays segment
check, the software version of the Indicator and then goes
into a weighing mode. The weighing mode and decimal
point position may be different depending on the setup of
the Indicator.

4.2 Turning Off Indicator

To turn the Indicator off, press and hold the ON ZERO/

Off

button until OFF is displayed.

4.3 Zero Operation

Press the ON ZERO/

Off button to zero the Indicator. The display acknowledges

by indicating the selected measuring unit followed by a zeroed display.

NOTE: Stable cursor must be lit to accept zero operation.

Place item to be weighed on the scale platform. The display indicates a sample
of 5kg, gross weight.

ON/ZERO

2II

PRINT

8QLWV

G/N/T

0HQX

TARE

Stable

Display

Hold

PCS

Gross

Brutto

Net

Tare

*

Stable

Gross
Brutto

Gross
Brutto

Stable

Place the container on the scale. Sample shown is 2kg.

Press the TARE button. Scale is tared and shows Net weight.

NOTE: Stable cursor must be lit to accept tare operation.

If the tare weight is removed from the scale, the Net weight is displayed as a
negative value

Stable

Net

Stable

Gross
Brutto

> 0 <

> 0 <

> 0 <

> 0 <

> 0 <

Stable

Net

*
