34
Data Bits Data Bits Data Bits Data Bits Data Bits
The total number of bits for Data, Parity and Stop must equal 9 or 10. (see examples).
The balance will not permit you to select a combination that does not equal 9 or 10. The
default setting is 7 data.
To set the number of data bits to 7 or 8:
EXAMPLES EXAMPLES EXAMPLES EXAMPLES EXAMPLES
8 Data + 2 Stop + No Parity = 10
8 Data + 1 Stop + Odd Parity = 10
7 Data + 1 Stop + Odd Parity = 9
1. Access the submenu.
2. accept.
3. to change setting.
4. .
Parity Parity Parity Parity Parity
Parity can be set to Odd, Even, None, or a marker of 0 or 1. The default setting is none.
To set parity, proceed as follows:
1. Access the submenu.
2. accept.
3. to change setting.
Baud Rate Baud Rate Baud Rate Baud Rate Baud Rate
This submenu is used to select the desired baud rate. There are five available baud
rates to choose from: 300, 1200, 2400, 4800 and 9600. The default setting is 2400
baud.
To view or change the baud rate:
1. Access the submenu to display the current setting.
2. .
3. to change setting. Normal baud rate is .
4. .
