XFile Version 2.12 – User Manual
EVS Broadcast Equipment – July 2009
Issue 2.12.D
181
Appendix 1:
XF[2] Hardware
HARDWARE DESCRIPTION
The XFile software is installed in a workstation operating under Windows XP
Pro. The standard system is Intel Core2 Duo E6300 Processor, Intel
Motherboard with DRAM 1GB and an EVS PCX board.
Note
The PCX1 board is not compatible with XFile v2.00 and higher.
The hardware components of the XF[2] platform (formerly called XFile[2])
are housed in a 3U rack cabinet equipped with 2 x ATA 133 750GB Mobile
Cartridges.
The XF[2] platform is included in the XNet in which XT[2] 6U, XT[2] 4U
SpotBox and AirBox servers interact via SDTI network.
This XF[2] platform is also equipped with two additional Gigabit Ethernet
adapters that support the jumbo frame mode for connections with the XT[2]
GigE ports and third parties.
