XFile Version 2.12 – User Manual
EVS Broadcast Equipment – July 2009
Issue 2.12.D
167
5.3 SHUTTLEPRO USE IN EDIT CLIP
MODULE
From XFile version 1.12, the ShuttlePRO can be used to perform the
commands corresponding to the buttons of the IN-OUT tab in the Edit Clip
module.
This chapter explains how to install and configure the ShuttlePRO for use in
the Edit Clip module. It also provides the ShuttlePRO and shortcut
commands in the IN-OUT tab of the Edit Clip module.
5.3.1 S
HUTTLE
PRO I
NSTALLATION AND
C
ONFIGURATION
To be able to use the ShuttlePRO, you need to install it on the XFile
workstation and configure it for use with the XFile application.
To install and configure the ShuttlePRO, proceed as follows:
1. Double-click the executable file cdi_shuttle_win_x.x.xx.exe
(x.x.xx correspond to the version number) delivered with the
ShuttlePRO and follow the installation wizard.
2. When this is installed, right-click the ShuttlePRO icon
on the right
of the Application toolbar. A contextual menu opens.
3. Select Open Control Panel from the contextual menu.
The Shuttle Device Configuration window opens.
In the ShuttlePRO tab, click the Options button and select Import
Settings from the contextual menu:
