Issue 2.12.D
XFile Version 2.12 – User Manual
EVS Broadcast Equipment – July 2009
16
C
OMBINED
M
ODE
GBE
+
XN
ET
This combined mode permits the transfers through the XNet when the
Gigabit network is not available, e.g. in case of disconnection of one server
from the Gigabit network.
3.1.3 B
ACKUP
C
HANNEL
A
SSIGNMENT
From XFile v.2.00, seven backup channels are available. You will assign
them according to your backup needs.
Two predefined configurations are available and are described below. If the
predefined configurations do not meet your requirements, you can define a
customized configuration.
The backup channel assignment will only affect the XFile and XStream
backup modes. They will not impact on the Restore, Publish and
Maintenance mode.
P
REDEFINED
C
ONFIGURATION
The following predefined configurations are available:
XFile Configuration
The XFile configuration provides the following backup functions:
•
1 channel for clip backups (XFile)
•
1 channel for playlist backups (XFile)
•
1 channel for thumbnail and image grabs (XFile)
•
3 channels for train backup (XStream)
•
1 channel for browsing in XStream
XStream Configuration
The XStream configuration provides the following backup functions:
•
6 channels for train backup (XStream)
•
1 channel for browsing in XStream
Important
As this configuration does not provide clip and playlist backups, nor
grabs, no thumbnails will be available for clips in the IP Director
application.
