XFile Version 2.12 – User Manual
EVS Broadcast Equipment – July 2009
Issue 2.12.D
139
Colour Codes in the Jobs List
The jobs displayed as records in the Jobs List of the XStream Load Jobs
window are highlighted with different colours depending on whether they will
or would be loaded or not into the XStream.
The following table explains the meaning of the different colour codes:
Colour Meaning
Green Selected jobs which will be loaded as scheduled job in
the XStream time grid. The value in the User Decision
column is set to ‘Schedule’.
Dark Blue Job selected in the Jobs List area.
The Retry Selected and Ignore Selected buttons will
only apply to the jobs selected in the Jobs List.
Light Blue Jobs which will not be loaded in the XStream time grid as
the user has asked them to be ignored. The value in the
User Decision column is set to ‘Ignore’.
Orange Jobs which could be rejected by the scheduler, for
example jobs based on a time code or presence of time
code jumps in the train.
Input on red
background Jobs which will be rejected by the scheduler because the
XT[2] server is no longer connected to the XNet network.
IN point on red
background Jobs which will be rejected by the scheduler because the
job will be outside the record train.
