background image

Issue 2.12.D

XFile Version 2.12 – User Manual

EVS Broadcast Equipment – July 2009

154

Field / Button

Description

XT Number and Name

Displays the XT[2] number and XT[2] name of the
selected XT[2] server. This is a read-only field.

Recorder channel

Allows (de)selecting the recorder channels of the

specified XT[2] server of which the record trains
will be backed up.

By default, all recorder channels available in the
given XT[2] configuration are deselected and
displayed on a pale green background.
Click the corresponding letter to select a camera.
The selected cameras are displayed on a bright
green background.

In QuickStart mode, it is not possible to back up
more record trains than the number of channels

assigned to the XStream. If the user attempts to
do this, the following error message will be
displayed on the QuickStart window:

Setup button

Gives access to the QuickStart Setup window.
For more information, see section ‘Setup in

QuickStart Mode’, on page 155

Record button

Starts the backup of the record trains on the
selected channels. The backup record starts

instantly.

Stop button

Stops the backup of the record trains on the
selected channels. The backup record will be
stopped when the user presses the Stop button.

As the backup files need to close properly, it can
however take some time before the job is
finalized. During this time, the message
“Finalizing …” will be displayed in the QuickStart
dialog box.
