Issue 2.14.B

XFile Version 2.14 – User Manual

EVS Broadcast Equipment – January 2011

62

3.4.3 N

ETWORK STATUS

The icon displayed in the center of the screen notices the current status of XNet:

Connection to XNet is successfully done

XFile is connecting

Connection to XNet failed

Local hardware failure has been detected

Standalone mode

3.4.4 D

ISK

U

SAGE AND

D

ISK

M

ODE

The remaining capacity and the capacity of disks are displayed in the lower part of

the window for each path.

The icon displayed in the lower part of the screen notices the current disk mode in
use:

Single Disk

Dual Disk

Mirroring
