4.3 TIME GRID
4.3.1 I
NFORMATION
D
ISPLAYED IN THE
T
IME
G
RID
Different color codes are used in the time grid to easily distinguish the various job
types. The color codes are the same in the Scheduler mode and in the QuickStart
mode.
The following table describes the various job types with the color associated to
each job type:
Background color Meaning
Yellow Job scheduled
Gold
(darker yellow)
Job in progress (still to be backed up)
Lime
(bright green)
Job in progress (already backed up)
Lime green
(darker green)
Job ended
Orange Job failed
Purple Job pending
When horizontal and/or vertical black lines are present within a job, it means that
a timecode jump has been detected. Right-clicking on the small vertical line will
display the TC value.
A job with thick hatching from left to right corresponds to an XML job.
A job with thin hatching from right to left corresponds to the selected job.
