OPERATING MANUAL REMOTE OPERATION
Release 2.0 (98/06) 4-5
4.3.2 Remote Analog Programming Procedure (continued)
Notes:
1. The rear panel SW1 switch is marked with the word OPEN on its upper surface. Any of the eight
switches on SW1 is OFF when it has been flipped up to break contact, ON when flipped down to close
contact.
2. Resetting switches SW1-3 or SW1-4, the programming scale selection switches, may require that you
recalibrate the programming circuit to maintain programming accuracy. See Section 5. Calibration.
3. Switches SW1-5, SW1-6, SW1-7, and SW1-8 are not required for remote programming. They remain
at the settings you have selected for your application.
4. Switches SW-1 to SW-4 can be set to their defaults (1 and 2 open, 3 and 4 closed) unless otherwise
specified in Table 4.3-2. See Section 4.2.1 Rear Panel SW1 Switch for default settings.
Table 4.3-2 Power Supply Settings for Different Programming Sources
Output Voltage
Programming
Output Current Limit Programming Source
Source 0-5Vdc 0-10Vdc 0-5k : : Resistor 0-10k : : Resistor None (Front
Panel Control)
0-5Vdc SW1:
3 and 4 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
3 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
2 closed, 3 and 4
open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
2 closed, 3 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
3 open.
J2 Jumper:
1 to 3.
0-10Vdc SW1:
4 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
default settings.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
2 closed, 4 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
2 closed.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
default settings.
J2 Jumper:
1 to 3.
0-5k : : Resistor SW1:
1 closed, 3 and 4
open.
J2 Jumper:
1 to 3 and 2 to 3.
SW1:
1 closed, 3 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
1 and 2 closed,
3 and 4 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
1 and 2 closed,
3 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
3 open, 1 closed.
J2 Jumper:
1 to 3.
0-10k : :
Resistor
SW1:
1 closed, 4 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
1 closed.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
1 and 2 closed,
4 open.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
1 and 2 closed.
J2 Jumper:
1 to 3 and 2 to 3. SW1:
1 closed.
J2 Jumper:
1 to 3.
None (Front
Panel Control) SW1:
4 open.
J2 Jumper:
2 to 3. SW1:
default settings.
J2 Jumper:
2 to 3. SW1:
2 closed, 4 open.
J2 Jumper:
2 to 3. SW1:
2 closed.
J2 Jumper:
2 to 3. SW1:
default settings.
J2 Jumper:
none.
