OPERATING MANUAL FEATURES AND SPECIFICATIONS
Release 2.0 (98/06) 1-3
1.3.1 Electrical Specifications (continued)
Table 1.3-2 Specifications for 100V to 600V Models
Models 100-12 150-8 300-4 600-2
Output Ratings: Output Voltage 1
Output Current
Output Power
0-100V
0-12A
1200W 0-150V
0-8A
1200W 0-300V
0-4A
1200W 0-600V
0-2A
1200W
Line Regulation: 2
Voltage (0.01% of Vmax + 2mV)
Current (0.01% of Imax + 2mA)
12mV
3.2mA 17mV
2.8mA 32mV
2.4mA 62mV
2.2mA
Load Regulation: 3
Voltage (0.02% of Vmax + 5mV)
Current (0.02% of Imax + 5mA) 27mV
7.4mA 35mV
6.6mA 65mV
5.8mA 125mV
5.4mA
Meter Accuracy:
Voltage (1% of Vmax + 1 count)
Current (1% of Imax + 1 count) 1.1V
0.13A 1.6V
0.09A 4V
0.05A 7V
0.03A
Output Noise (0-20MHz): Voltage (p-p) 150mV 150mV 200mV 400mV
Output Ripple (rms): Voltage
Current 4
10mV
100mA 20mV
50mA 30mV
25mA 80mV
15mA
Drift (30 minutes): 5
Voltage (0.05% of Vmax)
Current (0.6% of Vmax)
For Resistive Programming:
Voltage (0.6% of Vmax)
Current (0.6% of Imax)
50mV
72mA
600mV
72mA
75mV
48mA
900mV
48mA
150mV
24mA
1800mV
24mA
300mV
12mA
3600mV
12mA
Drift (8 hours): 6
Voltage (0.05% of Vmax)
Current (0.05% of Imax)
For Resistive Programming:
Voltage (0.3% of Vmax)
Current (0.3% of Imax)
50mV
6mA
300mV
36mA
75mV
4mA
450mV
24mA
150mV
2mA
900mV
12mA
300mV
1mA
1800mV
6mA
Temperature Coefficient: 7
Voltage (0.02% of Vmax/°C)
Current (0.03% of Imax/°C)
For Resistive Programming:
Voltage (0.06% of Vmax/°C)
Current (0.06% of Imax/°C)
20mV
3.6mA
60mV
7.2 mA
30mV
2.4mA
90mV
4.8mA
60mV
1.2mA
180mV
4.2mA
120mV
0.6mA
360mV
1.2mA
OVP Adjustment Range:
(5% to 110% of Vmax) 5-110V 7.5-165V 15-330V 30-660V
Efficiency: 8 0.84 0.84 0.85 0.85
1 Minimum output voltage is <0.15% of rated voltage at zero output setting.
2 For input voltage variation over the AC input voltage range, with constant rated load.
3 For 0-100% load variation, with constant nominal line voltage.
4 Current mode noise is measured from 10% to 100% of rated output voltage, full current.
5 Maximum drift over 30 minutes with constant line, load, and temperature, after power on.
6 Maximum drift over 8 hours with constant line, load, and temperature, after 30 minute warm-up.
7
Change in output per G C change in ambient temperature, with constant line and load.
8 Typical efficiency at 100Vac input voltage and full output power.
