AcuPanel 12 User Manual

1.4.3. Display Installation Process


Mount display brackets to the back of the display
Install the Display onto the wall mount bracket

1.4.4. Enclosed Parts







WARNGING:The maximum display weight the Wall mount bracket can support is below 25Kg.(55lbs). Please consult your distributor before

installing your device on different wall type.

1.5. Panel Mounting Instruction(Option)

1.5.1. Physical Dimensions

Your panel PC is equipped with fanless and no-ventilation-hole design and is durable to suit any critical environment. The following drawing
shows you detailed information for the dimensions.

ITEM

A

B

C

D

E

F

PARTS

QTY

1

1

4

4

4

4

SPEC

Please refer to

1.4.1

PLUG 07

L35

SCREW K

P3/16”

11/2”

SCREW

P S W

M4 L14

WNi

SCREW

P S W

M4

L10

WNi
