Page 34
SECTION 7—ARMS
34
Part No. 1143206
SECTION 7—ARMS
ƽ WARNING
After any adjustments, repair or service and before use, make sure that all attaching
hardware is tightened securely - otherwise injury or damage may result.
Before performing any maintenance, adjustment or service verify that On/Off
switch on the joystick is in the Off position.
Removing/Installing the Arms
ƽ WARNING
Increasing the width of the arms may affect the overall width of the wheelchair.
Ensure that there is enough clearance when attempting to pass through doorways
or other tight spaces, otherwise serious injury or damage may result.
NOTE: For this procedure, refer to FIGURE 7.1.
NOTE: Reverse this procedure to install the arms.
1. Loosen lock knob that secures the arm to the arm support tube.
2. Remove the arm from the arm support tube.
3. If necessary, repeat STEPS 1‐2 to remove the other arm.
FIGURE 7.1 Removing/Installing the Arms
Arm
Lock Knob
Arm Support Tube
Seat
NOTE: Semi‐Recline
Back seat shown. Fold
Down Back seats
remove/install the same
way.
