Page 31
SECTION 6—WHEELCHAIR OPERATION
Part No. 1143206
31
Pronto® M41 with SureStep®
MK5 SPJ-INT Joystick Switches and Indicators
NOTE: For the following information, refer to FIGURE 6.3.
FIGURE 6.3 MK5 SPJ-INT Joystick Switches and Indicators
On/Off Button
This button is located at the front of the joystick housing. It is used to turn the wheelchair
on and off, to remove the joystick from sleep mode (if programmed) and to lock or unlock
the joystick (if programmed).
Speedometer
The speedometer is used to show the maximum speed. The right‐most LED indicates
current maximum speed setting.
On/Off
Button
DETAIL “A” -
FRONT VIEW
Charger/
Programming
Input
Speedometer
Joystick
Bottom
Left LED
Information
Gauge
Display
Service Indicator
Decrease
Speed Button
(Tortoise)
Increase
Speed Button
(Hare)
