Accusys Acuta User’s Manual
28
5. Slide the disk drive into position in the
carrier, taking care not to damage the
IDE or S-ATA or power cables.
6. Turn the disk carrier upside down and
secure the disk in the carrier with four
screws.
7. Slide the loaded disk drive carrier into
the ACUTA 4/4S Controller Box and
push flat the carrier handle to lock the
carrier in position.
