Accusys Acuta User’s Manual
26
The USB port cannot be used when either of the IEEE 1394 ports is in use.
2 of IEEE 1394 port are for daisy chain to connect another IEEE1394 device.
Not for connecting ACUTA 4/4S to 2 host at mean time for access.
Host connection ports: Serial ATA interface version
RS-232 port
The RS-232 port is used if you want to monitor
the status of your array remotely. An RS-232
cable can connect ACUTA 4/4S to a terminal or
PC equipped with terminal emulation software.
Serial ATA port
The Serial ATA port is used to connect to a host
machine.
Loading drives into ACUTA 4/4S
We recommend that you use one of the following hard disk brands: Fujitsu,
IBM, Maxtor, Quantum, Seagate, or West Digital.
All four hard disks should be configured as Single Master.
The ACUTA 4/4S should be fitted with four hard disk drives (DISKs). Load each drive into a
drive carrier as follows:
註解 [V3]: replace the photo
