Page 7
7
SIS-PMS-LAN PROGRAMMABLE SURGE
PROTECTOR WITH LAN INTERFACE
All brands and logos are registered trademarks of their respective owners
2. Indicators and controls of the SIS-PМS-LAN
Power indicator
Non manageable
socket
Manageable socket 4
Manageable socket 3
Manageable socket 2
Manageable socket 1
Non manageable
socket
Indicator
Socket 4
Indicator
Socket 3
Indicator
Socket 2
Indicator
Socket 1
Main rocker
switch (Z)
Side panel #1
Side panel #2
Figure #1
