Gembird SIS-PMS-LAN User Manual
Page 33
33
SIS-PMS-LAN PROGRAMMABLE SURGE
PROTECTOR WITH LAN INTERFACE
All brands and logos are registered trademarks of their respective owners
If the status of SIS-PMS-LAN shows the device not to be Connected
- it could be due to the following reasons:
•
Incorrect IP/Port/Password specified in the Add LAN device window
•
PC is not connected to the local network
•
You are trying to access SIS-PMS-LAN from the PC which is not
allowed to do so. Change PC IP address or change IP filter list in
SIS-PMS-LAN hardware settings (see section 4.3 above)
•
SIS-PMS-LAN is not connected to local network. To check if SIS-
PMS-LAN is on your local network you can do so-called ping test:
•
Go to Start->Run
•
Type cmd
•
Type ping
the window which would appear
Suppose SIS-PMS–LAN with IP address 192.168.2.189 is
connected to the local network. Then the cmd window will look as shown
on the Figure #14 below:
