Gembird SIS-PMS-LAN - Manual (Page 15)

15
SIS-PMS-LAN PROGRAMMABLE SURGE
PROTECTOR WITH LAN INTERFACE
All brands and logos are registered trademarks of their respective owners
NOTE:
Antivirus or firewall software may block connection to SIS-
PMS-LAN. Please, configure antivirus/firewall to permit connection to
the IP address and port of your SIS-PMS-LAN
3.4. IP configuration
The utility Find SIS-PMS-LAN (see Figure #4 below) will run
automatically during the software installation but it can also be started
from Start/All Programs/Gembird/Power Manager. The IP range where
you would like to search for SIS-PMS-LAN will be set automatically
according to the IP settings of your LAN adapter but can be changed
manually in the Adapter subnet fields. Now press the Search button.
NOTE: only SIS-PMS-LAN within a local subnet can be found. If
your computer LAN adapter is not in the (default) subnet of SIS-PMS-
LAN (as might probably be the case if you chose option B section 3.2)
you will have to change its IP address manually to be able to find SIS-
PMS-LAN. For example if you wish to find SIS-PMS-LAN (with the default
IP 192.168.0.254), the IP address of your computer should be set as
192.168.0.XXX (where XXX stands for any digit, for example 1) and the
subnet mask should be 255.255.255.0.
After the searching the IP addresses of the found SIS-PMS-LAN
devices will appear in the list box. Select SIS-PMS-LAN which you want
to access, and press the Open button (see Figure #4 below).
